品牌：康明斯全系列配件、山推原厂配件
发动机功率：120
工作压力：14
起订：1副
供应：30副
发货：1天内
| 发动机功率 | 120 |
|---|---|
| 工作压力 | 14 |
| 使用质量 | 121212 |
| 适用机型 | SD16 |
| 外形尺寸(长×宽×高) | 5140*3388*3032 |
| 颜色 | 黄 |
| 组成结构 | 操纵系统 |
| 是否可定制 | 是 |
| 品牌 | 山推 |
| 型号 | SD16 |
| 所在地区 | 山东济宁 |
山推全车操纵杆零配件目录及总成件号
| 1 | 195-61-45150 | 手柄 knob | 1 |
| 2 | 195-43-44220 | 螺母 nut | 1 |
| 3 | 195-61-45140 | 护罩 guard | 1 |
| 4 | 16Y-86C-00005 | 座 pedestal | 1 |
| 5 | 01220-40508 | 螺钉 screw | 4 |
| 6 | 01601-20513 | 垫圈 washer | 4 |
| 7 | 16Y-86C-09000 | 摇臂 lever | 1 |
| 8 | 195-61-34130 | 轴承 bearing | 2 |
| 9 | 195-61-45180 | 轭 yoke | 1 |
| 10 | 195-61-45170 | 轴 shaft | 1 |
| 11 | 01010-50816 | 螺栓 bolt | 4 |
| 12 | 01643-30823 | 垫圈 washer | 8 |
| 13 | 195-61-45440 | 轴承 bearing | 2 |
| 14 | 16Y-86C-07000 | 支架 bracket | 1 |
| 15 | 01580-10806 | 螺母 nut | 4 |
| 16 | 16Y-86C-00004 | 轴 shaft | 1 |
| 17 | 16Y-86C-06000 | 支架 bracket | 1 |
| 18 | 195-61-45211 | 按钮 button | 1 |
| 19 | 16Y-86C-00003 | 叉口板 yoke | 1 |
| 20 | 04205-10822 | 销轴 pin, shaft | 3 |
| 21 | 04050-12016 | 开口销 pin, cotter | 5 |
| 22 | 195-61-45260 | 摇臂 lever | 1 |
| 23 | 01641-20812 | 垫圈 washer | 1 |
| 24 | 04210-20832 | 叉口板 yoke | 1 |
| 25 | 04244-40805 | 杆组件 rod ass’y | 1 |
| 26 | 16Y-86C-08000 | 锁块 block, lock | 1 |
| 27 | 195-61-45290 | 弹簧 spring | 1 |
| 1 | 16Y-25C-04000 | 操纵杆 control lever | 1 |
| 2 | 09361-01460 | 衬套 bushing | 1 |
| 3 | 09304-01240 | 手柄 knob | 1 |
| 4 | 16Y-25C-05000 | 摇臂 shaft | 1 |
| 5 | 04025-00532 | 销 pin | 1 |
| 6 | 04064-02012 | 挡圈 ring | 1 |
| 7 | 04250-41056 | 关节轴承 end | 2 |
| 8 | 04248-31011 | 杆 rod | 1 |
| 9 | 01582-11008 | 螺母 nut | 2 |
| 10 | 01593-11008 | 螺母 nut | 2 |
| 11 | 04050-12018 | 开口销 pin, cotter | 2 |
| 12 | 16Y-25C-06000 | 支撑板 floor | 1 |
| 13 | GB3045-81 | 关节轴承 GE20ES end, bearing | 1 |
| 14 | 04065-03715 | 挡圈 ring, snap | 1 |
| 15 | 04250-41056 | 关节轴承 end bearing | 2 |
| 16 | 04248-31011 | 杆 rod | 1 |
| 17 | 01582-11008 | 螺母 nut | 2 |
| 18 | 04050-12018 | 开口销 pin, cotter | 2 |
| 19 | 01593-11008 | 螺母 nut | 2 |
| 20 | 16Y-25-00003 | 接头 yoke | 1 |
| 21 | 16Y-25-00004 | 接头 yoke | 1 |
| 22 | 04248-31009 | 杆 rod | 1 |
| 23 | 01582-11008 | 螺母 nut | 1 |
| 24 | 01508-21006 | 左旋螺母 nut, left turn screw | 1 |
| 25 | 04050-12018 | 开口销 pin, cotter | 1 |
| 26 | 01641-21016 | 垫圈 washer | 1 |
| 27 | 04050-13020 | 开口销 pin, cotter | 1 |
| 28 | 04205-11028 | 销轴 pin | 1 |
| 29 | 04250-41056 | 关节轴承 end bearing | 1 |
| 30 | 04250-61056 | 关节轴承 end bearing | 1 |
| 31 | 04248-31013 | (左螺纹) left turn screw | 1 |
| 32 | 01582-11008 | 杆 rod | 1 |
| 螺母 nut |
| 1 | 195-78-75110 | 手柄 knob | 1 |
| 2 | 195-43-44220 | 螺母 nut | 1 |
| 3 | 195-61-45140 | 护罩 guard | 1 |
| 4 | 195-61-45130 | 座 pedestal | 1 |
| 5 | 01220-40508 | 螺钉 screw | 4 |
| 6 | 01601-20513 | 垫圈 washer | 4 |
| 7 | 01580-10806 | 螺母 nut | 6 |
| 8 | 01643-30823 | 垫圈 washer | 11 |
| 9 | 16Y-87C-01000 | 按钮 button | 1 |
| 10 | 16Y-87C-05000 | 摇臂 lever | 1 |
| 11 | 01010-50816 | 螺栓 bolt | 4 |
| 12 | 16Y-87C-06000 | 支架 bracket | 1 |
| 13 | 195-61-45440 | 轴承 bearing | 2 |
| 14 | 16Y-87C-04000 | 支架 bracket | 1 |
| 15 | 04050-12016 | 销 pin | 5 |
| 16 | 04205-10822 | 销轴 pin, shaft | 2 |
| 17 | 04210-20844 | 叉口板 yoke | 1 |
| 18 | 16Y-87C-09000 | 摇臂 lever | 1 |
| 19 | 01641-20812 | 垫圈 washer | 1 |
| 20 | 04210-20832 | 叉口板 yoke | 1 |
| 21 | 04244-40816 | 杆组件 rod ass’y | 1 |
| 22 | 16Y-87C-07000 | 锁块 block, lock | 1 |
| 23 | 16Y-87C-00002 | 轴 shaft | 1 |
| 24 | 195-61-45290 | 弹簧 spring | 1 |
| 25 | 01010-80830 | 螺栓 bolt | 2 |
| 26 | 16Y-87C-02000 | 摇臂 lever | 1 |
| 27 | 04010-00519 | 键 key | 1 |
| 28 | 16Y-96C-00006 | 衬套 bushing | 1 |
| 1 | 16Y-26C-11000 | 摇臂（左） lever, L.H | 1 |
| 2 | HK202616 | 轴承 bearing | 6 |
| 3 | 16Y-26C-07000 | 轴 shaft | 1 |
| 4 | 10Y-26-11000 | 杆 rod | 2 |
| 5 | 04205-10822 | 销轴 pin, shaft | 2 |
| 6 | 04050-12016 | 开口销 pin, cotter | 2 |
| 7 | 144-43-51130 | 接头 joint | 2 |
| 8 | 01508-20805 | 螺母 nut | 2 |
| 9 | 195-43-41360 | 缓冲器 damper | 1 |
| 10 | 01583-11006 | 螺母 nut | 2 |
| 11 | 195-43-41560 | 手柄（左） knob L.H | 1 |
| 12 | 195-43-41570 | 手柄（右） knob R.H | 1 |
| 13 | 19M-43-11170 | 螺母 nut | 1 |
| 14 | 01010-50816 | 螺栓 bolt | 1 |
| 15 | 01643-30823 | 垫圈 washer | 1 |
| 16 | 16Y-26C-05000 | 软轴 cable | 2 |
| 17 | 04205-11028 | 销轴 pin, shaft | 2 |
| 18 | 10Y-26-00006 | 叉口板 yoke | 2 |
| 19 | 04050-13018 | 开口销 pin, cotter | 2 |
| 20 | 16Y-26C-13000 | 板 plate | 1 |
| 21 | 16Y-26C-03000 | 摇臂（右）lever, R.H | 1 |
