Dwyer德威尔DPG-000 DPG-002 DPG-003 DPG-004 DPG-005数字压力表

产地	美国
售后服务	一年保修
品牌	Dwyer德威尔
型号	DPG-000
加工定制	是

Service: Compatible liquids and combustible gases (for FM listing see Agency Approvals below).
Wetted Materials: Type 316L SS.
Housing Materials: Polycarbonate front & back cover, anodized aluminum
extruded housing with recessed grooves, polycarbonate overlay, Buna-N O-rings,
316L SS sensor construction.
Accuracy: DPG-000: ±0.5% FS; DPG-100: 0.25% FS; ±1 least significant
digit @ 70°F (21°C)(includes linearity,hysteresis, repeatability).
Pressure Limit: 2x pressure range for models ≤1000 psi; 5000 psi for 3000 psi range;
7500 psi for 5000 psi range.
Enclosure Rating: Designed to meet NEMA 4/4X (IP66).
Temperature Limits: 0 to 130°F (-18 to 55°C).
Thermal Effect: Between 70 to 130°F is 0.016%/F; Between 32 to 70°F is 0.026%/F;
Between 10 to 32°F is 0.09%/F.
Size: 3.00" OD x 1.90" deep (max).
Process Connection: 1/4? male NPT.
Weight: 8.84 oz (275 g).
Display: 4 digit (.425" H x .234" W digits).
Power Requirements: (2) AAA alkaline batteries, included, user replaceable.
Battery Life: 2000 hours typical; Low battery indicator (60 hours in continuous use).
Auto Shut-Off: Gage: 60 minute auto shut off. Auto shut-off may be disengaged;
Backlight: 2 minute auto shut-off.
Agency Approvals: DPG-000: CE;
DPG-100: CE, FM approved to be intrinsically safe for Class I, Division I,
Groups A, B, C and D, for ranges 0-15 to 0-3000 psi.
DPG-000
DPG-100 with protective rubber boot Protective carrying case
DPG-100
PRESSURE Single Pressure Gages, Digital 85
