一拖东方红牌80马力T80型履带推土机

T80履带推土机

主要特点：

采用与英国里卡多公司合资技术生产的柴油发动机，噪音低、扭矩大、节能环保；

采用干式、双片、常结合主离合器，具有扭矩储备大，工作可靠等特点；

变速箱为4F+2R机械换档变速箱，操作简单，维修方便，使用可靠；

转向离合器为干式多片转向离合器，液压助力操纵，易保养，操纵轻便；

传动：采用两级、直齿、大模数齿轮传动，具有承载能力强，可靠性高等特点；

工作装置：具有多种工作装置可供用户根据需要选择；

操作环境：采用全封闭，低噪音驾驶室，有效降低耳旁噪音，提高舒适性，工作视野开阔；

采用电子监控的电气系统，对整机实时监控，保障机器正常运行；

本机使用可靠性高、维修保养方便、备件通用性强易采购；

T80CRAWLER BULLDOZER

MAIN FEATURES:

The diesel engine is manufactured by using joint venture technologies. The traction mechanism is of the semi-rigid suspension car type. The bulldozer adopts the two-plate dry primary clutch, which is easy to maintain. The steering is hydraulically supported and the bulldozer is hydraulically operated.

The machine is installed with the DONGFANGHONG  LR4105ZG52 boosting engine , with high power ,low noise , energy conservation and low consumption.

Gearbox is 4F+2R fixed-shaft mechanical gear shifting , applicable for various environments.

Integral trolley traveling construction adopting rigid chassis and semi-rigid hanger.

Advanced operation control system , fully hydraulic aided steering , with flexible and labor-saving operation.

Driver cab is welded with profile steel , with high strength , resistant against impact , and good protection safety .

Applicable for construction in narrow ground , with flexible working and high operation efficiency .

Standard heating and ventilation equipment , air conditioner optional .

Each maintenance center has humanized design , improving the convenience of repair and maintenance .

The complete machine has good economical power and high reliability , being an ideal machine for project construction .

技术参数TECHNICAL SPECIFICATIONS
