| 用途 | 五金 机械 |
|---|---|
| 形状 | 其它 |
| 材质 | 碳钢 |
| 旋向 | 左旋 |
| 样品或现货 | 现货 |
| 是否标准件 | 标准件 |
| 标准编号 | GB/T24425.3-2009 |
| 钢丝直径 | 20 |
| 弹簧外径 | 22 |
| 弹簧内径 | 18 |
| 节距 | 5 |
| 自由高度 | 15 |
| 品牌 | 茂异Tuz |
| 型号 | M4 |
| 公称直径 d | 螺距 p | d2 | T | ||
| min | max | min | max | ||
| M3 | 0.5 | 3.8 | 4.5 | 1.8 | 2.4 |
| M4 | 0.7 | 5.05 | 5.6 | 2.4 | 3.2 |
| M5 | 0.8 | 6.25 | 6.8 | 2.9 | 4 |
| M6 | 1 | 7.58 | 7.95 | 3.5 | 4.8 |
| M7 | 1 | 8.58 | 9.2 | 4 | 5.5 |
| M8 | 1 | 9.7 | 10.25 | 4.5 | 6.3 |
| M8 | 1.25 | 9.85 | 10.35 | 4.7 | 6.3 |
| M10 | 1 | 11.68 | 12.65 | 5.5 | 7.8 |
| M10 | 1.25 | 11.87 | 12.65 | 5.7 | 7.8 |
| M10 | 1.5 | 12.8 | 12.5 | 5.8 | 7.9 |
| M12 | 1 | 14.18 | 15 | 6.5 | 9.3 |
| M12 | 1.25 | 14.27 | 15 | 6.7 | 9.3 |
| M12 | 1.5 | 14.4 | 15 | 6.8 | 9.4 |
| M12 | 1.75 | 14.5 | 15 | 6.9 | 9.5 |
| M14 | 1.25 | 16.45 | 17.7 | 7.7 | 10.8 |
| M14 | 1.5 | 16.52 | 17.7 | 7.8 | 10.9 |
| M14 | 2 | 16.87 | 17.87 | 8.1 | 11 |
| M16 | 1.5 | 18.52 | 19.9 | 8.8 | 12.4 |
| M16 | 2 | 18.87 | 19.9 | 9.1 | 12.5 |
| M18 | 1.5 | 20.54 | 22 | 9.8 | 13.9 |
| M18 | 2 | 21.07 | 22 | 10.1 | 14 |
| M18 | 2.5 | 21.4 | 22 | 10.4 | 14.2 |
