| 材质 | 不锈钢 |
|---|---|
| 产地 | 广东 |
| 产品认证 | CE |
| 额定功率 | 20KW |
| 工作电压 | 380V |
| 工作温度 | 350℃ |
| 功率 | 18KW |
| 类型 | 不锈钢电热板 |
| 温度范围 | 0-300 |
| 用途 | 电加热 |
| 执行标准 | 企业标准 |
| 重量 | 100kg |
| 品牌 | OWADA/大和田 |
| 型号 | DHTOT-18 |
| 加工定制 | 是 |
| 连续使用寿命 | 10.0 |
| 加热器类型 | 电加热器 |
反应釜控温机特点：
Features
管路防爆装置
Explosion-proof equipment for pipelines
吹气回油功能
Air blowing and return oil return function
回油温度显示表
Thermometer for return oil
开机自动排气功能
Automatic air-exhausting function after startup
加热功率切换功能
Switchover of heating power
负压系统运转(选购)
Negative-pressure system (optional)
RS485通讯功能，实现自动化管理(选购)
RS485 communication function for automated management (optional)
即时冷却关机功能(选购)
Instant cooling return oil shut-down function
隔离式电器控制箱，延长电器使用年限
Isolated electric box for longer services lives of electric appliances
热油BY-PASS泄压回路
BY-PASS pressure release loop for hot oil
多点温度控制机组可订作
Customizable multi-point temperature control unit
油泵马力和加热功率可订作
Customizable horsepower and heating power of oil pump
电器采用OMRON. FUJI. TE. LG.
Brands OMRON, FUJI, TE and LG for electric appliances
温度控制范围: 油温+35℃→300℃
Range of temperature control: +25℃→300℃ for incoming water
304不锈钢一体管路,减少管阻及锈垢
304 stainless steel integrated pipelines for less pipe resistance and rust
控制方式: 采用进口微电脑或(选购)PLC控制
Control mode: imported microcomputer or PLC (optional)
安全保护完善,故障显示, 维修.保养无需专业人员
Perfect safety protection, fault display, easy repair and maintenance even free of professionals
反应釜控温机 反应釜油加热器,反应釜夹套油温控制机（系统）,反应釜导热油加热机技术参数
| 机型 | Model | 单位Unit | DHTOT-18 | DHTOT-36 | DHTOT-48 | DHTOT-60 | DHTOT-72 |
| 温控范围 | Controlrange | ℃ | 350℃ | ||||
| 电源 | Power | | AC3相380V50HZ | ||||
| 温控精度 | Temp.control accuracy | KW | PID±1℃ | ||||
| 加热能量 | Heating capacity | KW | 18 | 36 | 48 | 60 | 72 |
| 泵浦功率 | Pump power | KW | 2.2 | 3 | 5.5 | 5.5 | 7.5 |
| **大电力消耗 | Powersupply | KW | 26.5 | 39 | 53.5 | 65.5 | 79.5 |
| 泵浦流量/扬程 | Pump folw/Head | M3/H/M | 10/28 | 10.5/30 | 18/40 | 18/40 | 30/48 |
| 膨胀油箱 | Expansion tank capacity | L | 50 | 50 | 100 | 100 | 150 |
| 循环油配管 | Circulation oil pipe | DN | DN40 | DN40 | DN50 | DN50 | DN65 |
| 外型尺寸 | LxWxH | M | 1.6＊0.6＊1.4 | 1.6＊0.6＊1.4 | 1.6＊0.6＊1.4 | 1.7＊0.6＊1.4 | 1.8＊0.7＊1.4 |
| 重量 | Weight | KG | 220 | 240 | 350 | 480 | 600 |
