掘进机1AM1600星轮马达

产地	浙江
连接形式	螺纹
驱动方式	液压
适用范围	液压机械
适用介质	液压油
适用温度	100℃
压力环境	高压
品牌	1AM
型号	1AM1600
加工定制	是

铲板液压马达：IAM6-750， 铲板液压马达：NHM11-1200，铲板液压马达：NHM11-1200，一运液压马达：NHM6-600，一运液压马达：NHM6-400，一运液压马达：NHM6-400， NHM11-1200马达专业生产NHM系列五星马达。以下为产品型号
NHM1-63 NHM1-80 NHM1-100 NHM1-110 NHM1-125 NHM1-140 NHM1-160 NHM1-200

NHM2-100 NHM2-150 NHM2-175 NHM2-200 NHM2-250 NHM2-280

NHM3-175 NHM3-200 NHM3-250 NHM3-300 NHM3-350 NHM3-400

NHM6-400 NHM6-450 NHM6-500 NHM6-600 NHM6-700 NHM6-750

NHM8-600 NHM8-700 NHM8-800 NHM8-900 NHM8-1000

NHM11-700 NHM11-800 NHM11-900 NHM11-1000 NHM11-1100 NHM11-1200 NHM11-1300

NHM16-1400 NHM16-1600 NHM16-1800 NHM16-2000 NHM16-2400 NHM16-3000

NHM31-2500 NHM31-2800 NHM31-3000 NHM31-3150 NHM31-3500 NHM31-4000
NHM31-5000

型号	排量 (ml/r)	压力 (MPa)		扭矩(N.m)		转速范围(r/min)	重量(kg)
		额定 压力	压力	额定扭矩 (N.m)	单位扭矩(N.m/MPa)
NHM(KHM)1-63	64	25	32	325	9. 0	15-1500	20
NHM(KHM)1-80	78	25	32	300	12	15-1250
NHM(KHM)1-100	96	25	32	350	14	15-1000
NHM(KHM)1-125	126	20	25	380	19	15-1000
NHM(KHM)1-160	159	20	25	472	23	15-1000
NHM(KHM)2-100	113	25	32	420	18	15-1250	27
NHM(KHM)2-150	159	25	32	620	25	15-1000
NHM(KHM)2-175	180	20	25	526	28	15-1000
NHM(KHM)2-200	206	25	25	600	32	8-800
NHM(KHM)2-250	235	20	20	607	40	8-630
NHM(KHM)2-280	276	20	20	670	44	8-500
NHM(KHM)3-175	181	32	32	710	28	8-1000	35
NHM(KHM)3-200	201	32	32	800	32	8-800
NHM(KHM)3-250	254	32	32	949	40	8-630
NHM(KHM)3-300	289	25	25	864	46	6-500
NHM(KHM)3-350	340	25	25	1040	55	6-400
NHM(KHM)3-400	380	20	20	1054	63	6-400
NHM(KHM)3-500	450	20	20	1256	71	6-400
NHM(KHM)6-400	493	20	20	1483	79	6-400
NHM(KHM)6-450	397	32	32	1683	63	5-630	57.5
NHM(KHM)6-500	452	32	32	1463	72	5-630
NHM(KHM)6-600	491	25	25	1775	78	5-500
NHM(KHM)6-700	594	25	25	1633	94	4-500
NHM(KHM)6-750	683	20	20	1760	103	4-400
NHM(KHM)6-800	754	20	20	1884	110	4-320
NHM(KHM)6-850	804	20	20	2020	128	4-320
NHM(KHM)6-900	862	30	20	2097	138	4-320
NHM(KHM)8-700	896	30	20	2242	142	4-320
NHM(KHM)8-750	705	30	30	2401	112	4-400	82
NHM(KHM)8-800	806	25	30	2563	120	4-380
NHM(KHM)8-850	859	25	30	2185	128	4-350
NHM(KHM)8-900	914	25	25	2325	136	4-340
NHM(KHM)8-1000	999	32	25	2541	145	4-320
NHM(KHM)11-700	682	32	25	2667	158	4-300
NHM(KHM)11-800	782	32	32	2959	114	4-400	94
NHM(KHM)11-900	894	25	32	3480	120	4-400
NHM(KHM)11-1000	981	25	32	2974	140	4-400
NHM(KHM)11-1100	1104	20	25	3336	158	3-320
NHM(KHM)11-1200	1234	20	25	3512	177	3-320
NHM(KHM)11-1300	1301	20	20	3080	187	3-320
NHM(KHM)11-1400	1401	20	20	3323	197	3-250
NHM(KHM)16-1400	1413	32	20	5138	210	3-250
NHM(KHM)16-1600	1648	32	32	6158	262	2-400	170
NHM(KHM)16-1800	1814	25	32	5433	283	2-400
NHM(KHM)16-2000	2034	25	25	6030	323	2-320
NHM(KHM)16-2400	2401	20	25	5673	360	2-320
NHM(KHM)31-2500	2553	32	20	9523	405	2-320
NHM(KHM)31-2800	2683	32	32	10559	443	2-250
NHM(KHM)31-3000	3063	25	32	9135	485	1-200	298
NHM(KHM)31-3150	3218	25	25	9392	500	1-200
NHM(KHM)31-3500	3462	25	25	10220	544	1-200
NHM(KHM)31-4000	4152	20	25	12481	665	1-160
NHM(KHM)31-5000	4828	32	25	12387	825	1-160
NHM(KHM)100-6300	6765	32	20	22916	975	1-160
NHM(KHM)100-8000	8298	32	32	28744	1223	0.5-125	700
NHM(KHM)100-10000	9982	25	32	31942	1699	0.5-125
NHM(KHM)100-13000	12700	25	25	37210	2022	0.3-100
NHM(KHM)160-12500	13333	25	25	39460	1973	0.3-80
NHM(KHM)160-16000	16039	25	25	46420	2367	0.2-63	1000

ZBM3/80-F-H-K1Y,ZBM3/100-F-H-K1Y,带机械制动器液压马达
ZBM3/125-F-H-K1Y,ZBM4/160-F-H-K1Y,ZBM4/200-F-H-K1Y,带机械制动器液压马达
ZBM4/250-F-H-K1Y,ZBM4/320-F-H-K1Y,ZBM4/400-F-H-K1Y,带机械制动器液压马达
ZBM5/400-F-H-K1Y,ZBM5/500-F-H-K1Y,ZBM5/630-F-H-K1Y,带机械制动器液压马达
ZBM3/80-F-B-K1Y,ZBM3/100-F-B-K1Y,ZBM3/125-F-B-K1Y,带机械制动器液压马达
ZBM4/160-F-B-K1Y,ZBM4/200-F-B-K1Y,ZBM4/250-F-B-K1Y,带机械制动器液压马达
ZBM4/320-F-B-K1Y,ZBM4/400-F-B-K1Y,ZBM5/400-F-B-K1Y,带机械制动器液压马达
ZBM5/500-F-B-K1Y,ZBM5/630-F-B-K1Y,ZBM5/400-F-K-K1Y,带机械制动器液压马达
ZBM5/500-F-K-K1Y,ZBM5/630-F-K-K1Y,带机械制动器液压马达
ZBMR-80,ZBMR-100,ZBMR-125,ZBMR-160,ZBMR-200,带制动器液压马达
ZBMR-250,ZBMR-315,ZBMR-80P1AⅡY,ZBMR-100P1AⅡY,带制动器液压马达
ZBMR-125P1AⅡY,ZBMR-160P1AⅡY,ZBMR-200P1AⅡY,带制动器液压马达
ZBMR-250P1AⅡY,ZBMR-315P1AⅡY,ZBMR-80H1AⅡY,带制动器液压马达
ZBMR-250P1AⅡY,ZBMR-315P1AⅡY,ZBMR-80H1AⅡY,带制动器液压马达
ZBMR-100H1AⅡY,ZBMR-125H1AⅡY,ZBMR-160H1AⅡY,带制动器液压马达
ZBMR-200H1AⅡY,ZBMR-250H1AⅡY,ZBMR-315H1AⅡY,带制动器液压马达
