| 规格 | 各种 |
|---|---|
| 类型 | 重介质选矿设备 |
| 品牌 | 斯特尔 |
| 型号 | 各种 |
| 加工定制 | 是 |
| 生产厂商 | 江西斯特尔机械有限公司 |
| 所在地区 | 江西 |
试验LY摇床技术参数
Technical Parameter of laboratory LYShaking Table
LY摇床是供实验室开展矿石可选性研究，实验和小型选厂等进行重力选矿常用设备之一，适用于细粒和微细粒稀有金属、黑色金属、有色金属、贵重金属等矿石和煤的选别。该设备部仅可以作为一个独立的选矿作业，也可与跳汰机，螺旋选矿机，离心选矿机等其它选矿设备配合使用。本产品由原地矿部**指定企业生产，执行行业标准。
该设备依据入选矿物比重差和在往复不对称运动并呈倾斜的床面横向水流中的分层性能进行选别。具有不同比重矿物在床面上分带明显，精矿质量高，操作和调节方便等特点。
摇床面结构有矿砂和矿泥，材质有玻璃钢和铝合金。
LY shaking Table is one of the commonly usedequipment to conduct gravity concentration for feasibility and test of ores forlabs.and small beneficiation plant.It isapplicable for separations of fine-grainedand micro-grained rare meral,ferrous and non-ferrous metal,precious metal,coaland other minerals.It can carry out ore concentration operation independentlyand also can operate in conjunction with jig,cerew separator,centrifugalseparator and other equipment The product is produced by the only enterprisedesignated by the former Ministry of Geology and Mineral Mineral Resources,incompliance with the Industrial standards
The device is based on theproportion of selected minerals deviation and asymmetry in the reciprocatingmovement and tilt of the bed was horizontal flow in layered performance ofsorting. Have a different proportion ofminerals in the bed surface zonation obvious concentrate high quality, easyoperation and adjustment and so on.
Shaker surface structure of ore and mineral mud, steeland aluminum alloy material with a glass.
| 型号Model | 单位 Uite | LY2100/1050 | LY1100/500 |
| 床面尺寸Bde Size | mm | 2100/1050/850 | 1100/500/430 |
| 冲程Stroke | mm | 12-28 | 9-17 |
| 冲次Times of stroke | 次/min | 210-320 | 280-460 |
| 坡度Slope | o | 0-8 | 0-10 |
| 给料粒度Feed size | 矿砂mm | 2 | 2 |
| 矿泥mm | 0.074 | 0.074 | |
| 给矿浓度Feed density | % | 10-30 | 10-30 |
| 耗水量 t/h | t/h | 0.2-1 | 0.1-0.5 |
| 功率power | kw | 1.1 | 1.1 |
| 处理量Caparating size | 矿砂t/h | 0.4-0.8 | 0.1-0.2 |
| 矿泥t/h | 0.3-0.5 | 0.05-0.1 | |
| 外形Overall dimensions | mm | 3040/1050/1020 | 1530/500/700 |
| 重量Weighe | kg | 420 | 150 |
